New Floor Plan
Chateau30W
You must have specific consent permissions enabled in order to add items to your Favorites.
Sofa & Dinette Slide, Mid Split Bath, Rear Queen Bed
30W
- Length
- 32'
- Height
- 11'-2"
- Fuel Type
- Gasoline
- Automotive
- Ford
- Sleeping Capacity
- 5
- Exterior Storage
- 45.4 cu. ft.
Specifications
- Exterior Length (W/O Ladder)
- 32'
- Exterior Height (W/A/C)
- 11'-2"
- Exterior Width (W/O Mirrors)
- 8'-3"
- Exterior Storage
- 45.4 cu. ft.
- Awning Size
- 18'
- Interior Height
- 7'
- Fresh Water
- 40 gal
- Gray Water
- 30 gal
- Waste Water
- 25 gal
- Water Heater
- Tankless
- GVWR
- 14500 lbs
- GCWR
- 22000 lbs
- Wheel Base
- 18'-7"
- Seat Belt Capacity
- 6
- Sleeps
- 5
- Chassis
- Ford
- Engine
- 7.3L V8
- Horsepower & Torque
- 325 HP & 450 lb-ft Torque
- Hitch Weight Rating
- 8000 lbs
- Fuel Type
- gasoline
- Fuel Capacity
- 55 gal
Standards and Options
Standard
Optional
Model Specific
Standard
Optional
Model Specific
1” Fresh Water Tank Drain
100-watts Solar Charging System with Solar Charge Controller
30-amp Detachable Shoreline Power Cord
360° Siphon® RV Holding Tank Vent Cap
50 State 4.0 kW Dual Gas/LP Generator
Automatic Transfer Switch with Power Protection
Battery Disconnect Switch
Battery Tray - Holds up to Four (4) Batteries
Black Tank Flush System
Camp-Side Exterior Outlet Including USB Ports
Digital Monitor Panel
Exterior Camp-Side Spray Port
Exterior LP Gas Quick Connect
Exterior Solar Port
Holding Tanks with Heat Pads
Tankless Water Heater
Two (2) 11,000 BTU Power-Saver Air Conditioners
Whole Coach Water Filter Prep
Combo Washer/Dryer Prep
Standard
Optional
Model Specific
10” Touchscreen Dash Radio with Bluetooth®, Android Auto®, Apple CarPlay™ & SiriusXM® Prep
Aluminum Running Boards
Backup Monitor
Black Aluminum Wheels (Ford only)
Cruise Control
Deluxe Exterior Mirrors
Drink Holders
Emergency Engine Start
Heated/Remote Exterior Mirrors with Side View Cameras
Keyless Cab Entry Key Fob
Leatherette Reclining Captain’s Chairs
LED Taillights
Map Light
Molded Automotive Cockpit Headliner
Power Windows & Door Locks
Stainless Steel Wheel Liners
Steering Wheel Audio & Camera Control
Sun Visors
Three-Point Seat Belts for Driver & Passenger
Tilt Steering Wheel
Valve Stem Extenders
Windshield Privacy Curtain
Standard
Optional
Model Specific
12-volt DC Double Door Refrigerator
12-volt Power Bath Vent
Upgraded Recessed Three (3)-Burner Gas Cooktop with Glass Cover
Convection Microwave Oven with Air Fryer
Kitchen Countertop Accent LED Lighting
Kitchen Pantry Cabinet
Kitchen Waste Basket
Large Single Bowl Stainless Steel Sink & Single Handle Faucet with Pull-Down Sprayer
Pop-Up Wireless Phone Charger with 110-volt Outlets & USB/USB-C Plugs
Pressed Laminate Kitchen Countertops with Under Mounted Sink & Stainless Steel Sink Cover
Range Hood with Task Light above Cooktop
Standard
Optional
Model Specific
12-volt LED Smart Exterior 32” TV on Swivel Bracket with Bluetooth® Built-In Sound Bar
40” Smart TV in Living Area
Bedroom TV Prep
Satellite Mounting Backer in Roof
Winegard® Digital TV Antenna with 4G/5G Prep
Standard
Optional
Model Specific
12-volt Power Vent in Bathroom
12-volt Outlet for CPAP Machine
Bedroom USB Power Charging Center for Electronics
Bedspread & Pillow Shams
Designer Headboard
Porcelain Foot Flush Toilet
Queen Bed
Robe Hook(s) Inside Bathroom
Shower with Upgrade Retractable Shower Door
Skylight in Shower
Stainless Steel Bathroom Sink
Wardrobe
Standard
Optional
Model Specific
8,000 lbs Trailer Hitch
Automatic Leveling Jacks with Touchpad Controls
Drop Down Stairwell Entrance Step with Accent Light Under Step on Separate Switch
Electric Stabilizing Jack System
Entry Door with Deadbolt Lock
Exterior Grab Handle
Flush Mount Compartment Doors with Slam Latches (Select Locations)
Ford® E-Series Chassis - 7.3L V8 with 325HP & 450 lb-ft Torque with TPMS
Framed Windows
Full-Body Paint Package with Protective Mask IPO Partial Paint
HD-MAX® White Exterior with Partial Paint (No Taped Graphics)
HD-MAX® White Fiberglass Exterior with Graphics Package
One-Piece Fiberglass Front Cap
Pet-Link™ Multi-Purpose Tie-Down
Portable Table in MEGA-Storage™ Compartment
Power Patio Awning with Integrated LED Lighting
Premium One-Piece Domed Roof Membrane
Roof Ladder
Rotocast Storage Compartments with Lights
Slideout Room Topper Awning(s)
SmoothTECH™ Suspension System
Upper Rear Cap
Vacu-Bond Laminated Roof, Walls & Floor with Block Foam Insulation
Welded Tubular Aluminum Roof & Sidewall Cage Construction
Standard
Optional
Model Specific
84” Interior Ceiling Height
Cabover Bunk Safety Child Net
Cabover Sleeping Area with Cup Holders & Telescoping Bunk Ladder
Ceiling Ducted Air Conditioning System
Entry Grab Handle
Fabric Valance with Framed Interior Windows
Fire Extinguisher
Full Extension Soft Close Metal Ball-Bearing Drawer Guides
Hard Vinyl Ceiling
Leatherette Dream Dinette® Booth with Cup Holders
LED Lighting
Manual Vent at Cab-Over Bunk with Shade
Passenger Seat Belts in Select Areas
Pressed Laminate Countertops
Residential Vinyl Flooring
Rubber Tread Entry Steps with Lighted Step Well
Single (1) Child Safety Tether in Dinette
Smoke, LP Gas & Carbon Monoxide Detectors
Window Privacy Roller Shades
Cassette Shades with Integrated Pleated Blinds
Soft Close Cabinet Door Hinges
Leatherette Jackknife Sofa
Leatherette Theater Seating
