A.C.E.29D
You must have specific consent permissions enabled in order to add items to your Favorites.
Full Wall Slide, Exterior Kitchen & TV
29D
- Length
- 30'-9"
- Height
- 12'-2"
- Fuel Type
- Gasoline
- Automotive
- Ford
- Sleeping Capacity
- 6
- Exterior Storage
- 66 cu. ft.
Specifications
- Exterior Length (W/O Ladder)
- 30'-9"
- Exterior Height (W/A/C)
- 12'-2"
- Exterior Width (W/O Mirrors)
- 8'-3"
- Exterior Storage
- 66 cu. ft.
- Awning Size
- 228'
- Interior Height
- 7'
- Fresh Water
- 50 gal
- Waste Water
- 40 gal
- Water Heater
- Tankless
- GVWR
- 18000 lbs
- GCWR
- 23000 lbs
- Wheel Base
- 15'-10"
- Seat Belt Capacity
- 7
- Sleeps
- 6
- Chassis
- Ford
- Engine
- 7.3L V8
- Horsepower & Torque
- 335 HP & 468 lb-ft Torque
- Hitch Weight Rating
- 8000 lbs
- Fuel Type
- gasoline
- Fuel Capacity
- 80 gal
Standards and Options
Standard
Optional
Model Specific
Standard
Optional
Model Specific
14” Touchscreen Dash Radio with Bluetooth®, Android Auto®, Apple CarPlay™ & SiriusXM® Radio
19.5” Tires with Stainless Steel Wheel Liners
Automatic Headlights
Backup Monitor
Cab Light
Conversation Mirrors
Cruise Control
Dash Workstation with 110-volt & 12-volt Outlets
Drink Holders
Heated/Remote Exterior Mirrors with Side View Cameras
Power Drop-Down Hide-Away Overhead Bunk with Cotton Cloud™ Mattress & Bunk Ladder
Power Privacy Shade & Sunvisor at Windshield
Privacy Curtain on Side Windows
Reclining/Swivel Leatherette Captain’s Chairs
Steering Wheel Audio & Camera Control
Three-Point Seat Belts for Driver & Passenger
Tilt/Telescoping Leather Steering Wheel with Audio Control
Touch N’ Go Control™ Panel: Tank Levels, Generator AGS, Emergency Start Switch & Slideout Controls
Valve Stem Extenders on Rear Wheels
Standard
Optional
Model Specific
12-volt Fan with Wall Switch in Bathroom
Bedroom 110-volt Outlet on Inverted Circuit for CPAP Machine
Designer Headboard, Bedspread & Pillow Shams
King Size Bed
Porcelain Foot Flush Toilet
Printed Shower Surrounds & Pans
Pullout Kibble Station™ with FDA Approved Pet Bowl Liner
Shower with Curved Anti-Microbial Shower Curtain
Skylight in Shower
Standard
Optional
Model Specific
8,000 lbs Trailer Hitch with 7-Pin Connector
Automatic Leveling Jacks with Touchpad Controls
Basement Pass-Through Storage Compartment
Electric Entry Step
Entry Door with Deadbolt Lock
Exterior Grab Handle
Ford® F-53 Chassis
Framed Windows
HD-MAX® Exterior with Graphics Package
Large Panorama One-Piece Windshield
One-Piece Fiberglass Front Cap
Pet-Link™ Multi-Purpose Tie-Down
Power Patio Awning with Integrated LED Lighting
Premium One-Piece Domed Roof Membrane
Roof Ladder
Rotocast Storage Compartments
Side-Hinged Flush Mount Radius Compartment Doors
Slideout Room Topper Awning(s)
TPO Upper Rear Cap
Vacu-Bond Laminated Roof, Walls & Floor with Block Foam Insulation
Welded Tubular Aluminum Roof & Sidewall Cage Construction
Welded Tubular Steel Floor
Standard
Optional
Model Specific
1,000-watts Inverter
1” Fresh Water Tank Drain
100-watts Solar Panel with Controller
360° Siphon® RV Holding Tank Vent Cap
50-amp Detachable Shoreline Power Cord
Automatic Generator Start
Automatic Transfer Switch with Power Protection
Battery Disconnect Switch
Black Tank Flush System
Dual 13,500 BTU Roof Air Conditioners
Enclosed Holding Tanks with Heat Pads
Expandable Solar Port
Exterior LP Gas Connection
Macerating System for Black Tank
Onan® RV QG 4000 Gas Generator
Outside Shower
Second Auxiliary House Battery
Tankless Water Heater
Standard
Optional
Model Specific
32” LED Smart TV in Bedroom
40” LED Smart TV in Living Area
Cable TV Video Distribution Ready
Exterior 32” TV on Swivel Bracket with Bluetooth® Built in Sound Bar
Exterior Kitchen with 2-Burner Pullout Griddle, Temperature Adjustable Spray Port, Prep Surface & Accessories
Satellite Mounting Backer in Roof
USB Charging Ports - Bedroom & Living Room
Winegard® ConnecT™ 4G+ - WiFi / 4G LTE / TV Antenna
Standard
Optional
Model Specific
12-volt Fan in Living Room
84” Interior Ceiling Height
Cali Collection - Two-Toned Cabinets with California White Uppers, Coastline Grey Lowers & Gold Hardware
Ceiling Ducted Air Conditioning System
Dream Dinette® Booth with Cup Holders
Fabric Valance with Wood Framed Windows
Fire Extinguisher
Flat Panel Cabinet Doors with Hardware
Full Extension Soft Close Metal Ball-Bearing Drawer Guides
Hard Vinyl Ceiling
Leatherette ”Theater Seats” with Integrated Footrests
Leatherette Sofa Bed
LED Lighting
Metal Entry Grab Handle
Passenger Seat Belts in Select Areas
Pressed Laminate Tops
Residential Vinyl Flooring
Retreat Collection - Two-Toned Cabinet Doors with Natural Linen Uppers, Wabash Cherry Lowers & Black Nickel Hardware
Rubber Tread Entry Steps with Lighted Step Well & Utility Storage
Single (1) Child Safety Tether in Dinette
Smoke, LP Gas & Carbon Monoxide Detectors
Window Privacy Roller Shades
Wireless Phone Charger with USB Plug in Dinette Table Top
Standard
Optional
Model Specific
12-volt DC Double Door Refrigerator
3-Burner Gas Cooktop/Oven with Bi-Fold Glass Cover
Glass Tile Backsplash
Large Single Bowl Rectangle Stainless Steel Sink & Single Handle Faucet with Pull-Down Sprayer
Microwave Oven (1 cu ft)
Solid Surface Galley Top with Roll-Up Sink Covers & Accent Lighting
Trash Container
